Revival 520 Sportz


$0.00
* Sail Away

Our versatile R520 SportZ Edition hits the water with all the essentials and many so called “extras” that other boat brands force you to pay for: bowrails, bilge pumps, internal lighting, under-floor fuel tanks, dry and wet storage and loads more. Simply strap on the outboard of your choice and get it wet.

Boat Details
  • Make: Revival
  • Name: 520 Sportz
  • Model Number: N/A
  • Year: 2022
  • Length: 5.25 metres
  • Width: 2.2 metres
  • Dry Weight: 650 kg
  • Hull Material: Fibreglass
  • Hull Type:
  • Passenger Capacity: 6
  • Boat Usage:
  • Steering: Mechanical Steering
  • Registration Number:
  • Registration Expiry:
  • Stock Number:

  • Hull Length (mm)... 5250mm
  • Hull Beam (mm)... 2200mm
  • Transom Deadrise... 20 degrees
  • Transom Height (inches)... 25""/XL
  • Height on Trailer to top of Windscreen... 2070mm
  • Overall Length on Trailer (mm)... 6900mm (aprox.)
  • Draft (mm)... 300mm (aprox.)
  • Hull Weight (kg) - dry... 650kg
  • BMT Weight (kg) - dry... 1250kg
  • Fuel Capacity (lt)... 100lt
  • Number of People... 6 Adults
  • Horsepower... 75 - 115hp
  • Max Outboard Weight (kg)... 185kg
  • Estimated Cruise Speed (kph) w/Mid-Range hp... 42kph
  • Estimated WOT Speed (kph) w/Mid-Range hp... 72kph
  • Internal Cockpit Length (mm)... 1800mm
  • Internal Cockpit Beam (mm)... 1800mm

FEATURES

STANDARD HULL FEATURES...

  • 10 Year Hull Warranty
  • Anchor Storage Compartment with Lockable Lid
  • Foam-Filled Hull
  • Hand Laminated Fibreglass Hull and Deck
  • High Quality Gelcoat Hull & Deck (Std Colour is Ultra White Premium)
  • Hull & Deck - All White Gelcoat with Edition Specific Stripes and Graphics
  • Rear Tow Eyes

STANDARD DECK FEATURES...

  • Bollard Split - Stainless Steel
  • Bow Sprit (Moulded) with Stainless Steel Bow Roller
  • Large Bow Storage/Casting Area Compartments in Walkthrough & Floor Storage Boxes with Carpeted Hinged Lids
  • Rear Fixed Cleats - Stainless Steel (2)
  • Split Bowrails - Marine-Grade Stainless Steel (Australian Made)

STANDARD COCKPIT FEATURES...

  • Carpeted Floor and Sides - Glued
  • Cockpit Side Pockets - Moulded Fibreglass (Gelcoated) White
  • Ports and Starboard Recessed Grab Rails

STANDARD FISHING FEATURES...

  • Stainless Steel Economy Rear Rod Holders (2)

STANDARD SEATING...

  • Compact Helm Seats on Fixed pedestal with Slide & Swivel (Port & Starboard) - Non Flip Up in Grey with Charcoal Trim
  • Upholstered Full Width Removable Fold-Down Rear Lounge
  • Padded Transom Backrest

STANDARD STORAGE FEATURES...

  • Rear Port & Starboard Bait Wells (Non-Plumbed)
  • Underfloor Kill Tank Storage Locker - Moulded Fibreglass
  • Port Side Coaming Storage Compartment

STANDARD STEERING...

  • Mechanical Non-Feedback Steering System
  • Multi Spoke Steering Wheel

STANDARD HELM & PASSENGER FEATURES...

  • Panic Rail for Passenger - Stainless Steel
  • Lockable Glove Box Port Side

STANDARD ELECTRICAL & LIGHTING...

  • Coaming Lights x 2 (Round)
  • Navigation Lights
  • Water-Resistant Switch Panel
  • 1150 GPH Bilge Pump Hose and Outlet

STANDARD WINDSCREEN...

  • Windscreen Grab Rail
  • Windscreen (3-Piece with Support Brace)

STANDARD FUEL SYSTEM...

  • Underfloor 100L Polyethelene Fuel Tank with Sender
  • Fuel Tank Breathers and Filler Cap in Engine Well

STANDARD GRAPHICS & BADGING...

  • Colour-Coordinated "SportZ" Graphics
